Cymatix Motors & Brakes

At Cymatix, we have leveraged our 40+ years of industry experience to not only help customers size/select rotary brushless servo motor solutions but have the ability to provide custom motors and configurations to best meet application demands. Our designs are based on motor part sets which are manufactured overseas and stocked locally in Petaluma CA. By offering a modular design, we can generate hundreds of iterations of motor solutions based on inventory components. For unique applications, where we don’t have a solution on the shelf, our team of industry experts are here to help and will design a custom solution that is uniquely tailored to meet your needs.

Cymatix Motor Catalog.PDF

Note: * indicates BISCC-C Absolute encoder available

Motor Part Number	Flange [mm]	Length [mm]	Voltage [Vdc] Rated / Peak	Torque [Nm]	Speed [rpm]	Power [Watts]	Encoder Res [ppr]	List Price [$]	CAD Models	Spec Sheets
MP24-2B-MX2500-NN-01	24	58	24 / 170	0.1	3000	30	2500*	$451	.STEP	.PDF
E017-1A-MX5000-NN-001	42	53	24 / 170	0.1	3000	30	5000*	$253	.STEP	.PDF
E017-2A-MX5000-NN-001	42	72	24 / 170	0.2	3000	60	5000*	$266	.STEP	.PDF
E017-3A-MX5000-NN-001	42	90	24 / 170	0.3	3000	90	5000*	$293	.STEP	.PDF
EP23-1A-MX5000-CN-001	57	71	72 /170	0.39	6000	220	5000*	$388	.STEP	.PDF
EP23-2A-MX5000-CN-001	57	97	72 / 170	0.63	5250	350	5000*	$653	.STEP	.PDF
EP23-3A-MX5000-CN-001	57	122	72 / 170	0.78	5750	467	5000*	$693	.STEP	.PDF
MP60-3A-MX5000-CN-001	60	143	48 / 170	1.3	4000	540	5000	$410	.STEP	.PDF
MP60-3B-MX5000-CN-001	60	143	72 / 310	1.3	4000	540	5000	$410	.STEP	.PDF
MP60-3C-MX5000-CN-001	60	143	170 / 310	1.3	3000	400	5000	$410	.STEP	.PDF
MP80-2B-BX2500-CN-001	80	153	310 / 310	2.44	3000	765	2500	$452	.STEP	.PDF
MP80-2B-BX2500-CB-001	80	190	310 / 310	2.44	3000	765	2500	$610	.STEP	.PDF
EP34-2A-MX2500-CN-001	82	153	48 / 170	2.44	3000	765	2500*	$452	.STEP	.PDF
EP34-2B-MX2500-CN-001	82	153	310 / 310	2.44	3000	765	2500	$452	.STEP	.PDF

Cymatix Brakes

If your application is vertical, adding a motor brake is highly recommended. These brakes mount to the front of the motor and internally have an electro-mechanical braking mechanism, which opens by applying 24Vdc. If a voltage signal is not sent to the brake, it will not release, preventing any rotational motion from occurring. This voltage signal can be commanded or operated as a fail-safe in the event of a power failure. When the brake no longer receives voltage, it will stop motion thus preventing the load from moving and damaging the machine or the parts being processed in the machine.

Motor Brake PN	Flange [mm]	Length [mm]	Torque [Nm]	Voltage [Vdc]	Shaft Input [mm]	List Price [$]	CAD Models	Spec Sheets
BPC017-21-003	42	49	0.113	24	5	$110	.STEP	.PDF
BPC023-24-027	57	48	0.5	24	6.35	$180	.STEP	.PDF
BPC023-24-026	57	62	0.8	24	6.35	$200	.STEP	.PDF
BPC024-24-002	60	70	1.5	24	14	$334	.STEP	.PDF
BPC034-24-003	82	78	1.7	24	12.7	$207	.STEP	.PDF

Servo motors require drives/controls to run.
